There are three commonly used control methods for parallel hole spacing:
(1) Use the scribed line to control the hole distance, scribe the line on the surface of the workpiece, draw the hole center line and the hole machining reference circle at the lathe hole machining position, and proof and punch the hole on the center and the reference circle. Glue a pin on the boring bar, adjust the position of the table and the pin so that the revolving track of the pin coincides with the scribing position of the hole on the workpiece. Prefabricated holes, pre-check hole spacing. Adjust the worktable according to the difference until the hole spacing requirements of the pattern are met.
(2) Use the worktable dial to control the hole distance, and use the tool-touching method or the scribing method to preliminarily adjust the processing position of the hole, and grasp the direction of the gap between the table movement. Prefabricated holes, pre-check hole spacing. Use the dial to move the worktable to adjust the hole spacing according to the difference until the hole spacing requirements of the pattern are met.
