Direct tool setting skills for large CNC lathe machining：
Select the center of the right end face of the part as the tool setting point and set it as the zero point. After the machine tool returns to the zero point, each tool that needs to be used will set the tool with the center of the right end face of the part as the zero point; When the tool touches the right end face, input Z0 and click measurement, and the tool compensation value of the tool will automatically record the measured value, which means that the tool setting of Z axis has been completed. The tool setting of X axis is the trial cutting and tool setting, and the part excircle is less with the tool. Measure the value of the machined excircle (for example, X is 20mm) and enter X20. Click measurement, and the tool compensation value will automatically record the measured value. At this time, the X axis is also aligned; This tool setting method will not change the tool setting value even if the machine tool is powered off and restarted. It is suitable for mass production of the same part for a long time, and there is no need to reset the tool when the large-scale CNC lathe is shut down.
